Motor application ferrite ceramic arc magnet

Material:Sintered Ferrite (Hard Magnetic)





Tolerance:According to the technical requirements of the drawing

Packing:Standard air or sea packing

Pull Force:No test

Delivery Time:12-25 days

Place Of Origin:Dongguan, China

Working Temperature:< 250℃

Magnetizing Direction:Radial pairing

Surface Magnetic Strength:Greater than 1130 gauss

  • Product Details
  • Why Choose Us
  • FAQs
  • Packing & Delivery

Arc segmented ferrite for motors is a common magnetic material with the following main features;

The ferrite magnet is made into an arc-shaped structure, which is divided into multiple arc segments according to a certain pole spacing.

Each arc structure is equivalent to a magnetic pole, and multiple poles form a multi-pole magnetic ring.

The arc-shaped design is in line with the structure of the motor cylinder, which is conducive to improving the utilization of magnets.

Segmented structure can reduce the turn-to-turn cross slot, reduce magnetic leakage phenomenon.

Ferrite is inexpensive and can be used to produce large-size curved structures to provide sufficient magnetic flux.

With optimized design, iron loss can be controlled at a low level.

Good thermal stability, suitable for motors with large heat generation.

It can generate large attraction with the rotor core to provide stable torque output.

It is a kind of low cost and reasonable performance motor magnet choice.

In summary, the curved segmented ferrite ring structure is simple, practical, cost-effective, and widely used in various types of motors.

Dongguan Courage Magnetoelectric Technology Co., Ltd. is a Chinese magnet manufacturer specializing in the production of strong neodymium magnets, ceramic ferrite magnets, motor multipole magnets. We have cooperated with many customers for many years, mainly for the following reasons:

1, we are good at processing high performance, high precision, high difficulty magnet, especially in the field of DC motor magnet, have strong professional knowledge, experience.

2, We have a professional production, sales, design team, based on the industry for more than 14 years.

3, we have advanced magnet production and testing equipment, according to customer requirements to design, production of special requirements of magnet products,

4. The company's products have passed SGS, ROHS, REACH certification and a complete ISO9001 quality management system, specializing in providing high-quality permanent magnet products to customers in various countries.

5. Experience in serving Western, Asian and North American companies, we also have close ties with other regions, fedex or DHL can deliver,

6, Even if our customers do not know much about magnets, we will help and provide accurate product solutions.

You may be interested in these magnet problems (Q&A) ;

1、Could you give me some magnet samples?

Yes, we have magnets in stock to help you get samples as soon as possible.

2、How long will it take me to get a reply to your email or inquiry?

We will contact you as soon as possible within 12 hours.

3、Why don't the magnets on your company website say the price?

Magnets belong to functional products, most customers have different requirements for magnets, such as material, shape, performance, tolerance, temperature resistance, purchase quantity, etc., we can customize processing according to your requirements, so we need to clarify your specific needs and then give you a quote.

4、Do you guarantee the quality of your magnet products?

We have ISO,SGS and REACH certifications. If necessary, we can send you relevant materials.

5、May I come and visit your magnet factory?

Sure. We'll show you around our factory if you want.

6、What is your delivery time?

See if there is spot stock, if there is immediately can be arranged to send, if there is no need to process in 10-30 days or so, depending on what kind of magnet.

More Questions and Answers about Magnets:

Courage magnet manufacturer magnet packaging and delivery method:

China Courage magnet manufacturer magnet packaging and delivery method

The magnets we make are mainly delivered to you by sea or air. The packaging is generally neutral packaging, shielded packaging, vacuum packaging, pallets, etc., which can be packed according to your requirements.


a: Express (TNT, DHL, FedEx, UPS, etc.), air freight, sea freight.

b: The weight is less than 40Kgs. We suggest sending it to you by shield box.

c: It weighs between 40 kg and 100 kg. It can be expressed or shipped by air.

d: The weight is over 100 kg. We suggest sea transportation.
